19
1
ATTACH VENTING: OPTION 2 - NON DUCTED
RECIRCULATING
Required Activated Charcoal Filter
Accessory - sku # - FILTER7
For Non-Ducted Recirculation venting route the ductwork to a location
above the hood where the discharge is vented back into the room.
Use the included Recirculation Vent Grill
C
to cover the opening. Secure
the grill with the 2 screws
G
provided in the Install Kit.
A straight 5" round duct that is at least 15" in length should be used to lead air
from the top of the hood exhaust outlet to the exit of the cabinet above.
´
C
G
4 3/4"
Pozi Screwdriver
To Next Page
