2.3 Terminal position
Verify if the required terminal position meets the local installation regulations regarding
disturbance, good functioning and ventilation:
• The terminal must be located so that the outlet is not obstructed. If the flue
terminal is located within 2 meters of a footway path or where people could come
into contact with it, then a suitable terminal guard must be fitted
• Terminals located close to shared walkways, footpaths etc. could be subject to
legal constraints and this should be pointed out to the customer before installation.
If in any doubt about flue location advice should be sought from local building
control, or if appliance-related, from the manufacturer including wherever possible
a dimensioned sketch
• Avoid locating the terminal in close proximity to plastic materials such as gutters or
other combustibles. If this is unavoidable then a suitable deflector should be made.
• Some important requirements for a good functioning are
• The wall-mounted terminal has to be at least 0,5 m off:
o Corners of the building
o Below eaves
o Balcony's etc. unless the duct is dragged to the front side of the overhanging
part
o The roof mounted terminal has to be at a distance of at least 0.5 meters of
the sides of the roof, excluded the ridge
