1.4). Take the glass away.
3.5 Connection with use of concentric duct material
• Make a hole of ø 153 mm for the wall or roof mounted terminal.
• The horizontal pipes need to rise away from the appliance at a rate of 3 degrees
per metre
• Build the system starting from the appliance on.
• Make sure you place the pipes in the right direction, the narrow end towards the
appliance.
• Make sure the pipes are fixed sufficiently, a wall clamp every 2m, so the weight of
the pipes is not resting onto the appliance.
• The outside of the pipe can become hot (140 degrees). Stay 50 mm away from any
Timber wall surface or sealing. Make sure to provide sufficiently heat resistant
isolation when going through the wall or roof.
• Because of expansion or cooling down the concentric pipes can turn loose. It is
recommended to fix the pipes with a self tapping screw or use aluminium tape
To get the exact measure flue length you can use cut down concentric pipe, wall mounted
terminal or roof mounted terminal. To obtain a smoke sealed connection, the inner pipe
must be 20 mm longer then the outside pipe.
3.6 Placing the log set
Place the log set according to the figures 1.6.
As desired the bottom of the appliance can be spread over with the delivered embers.
