EN 7
Fig.5 Fig.6
2.3 CONNECTING THE HOB TO GAS SUPPLY
Having installed the hob in the worktop, connect the appliance to internal gas supply system.
Note:
1. The connection of the hob to the gas supply system should be made in
accordance with the regulations in force.
2. All activities involved in connecting the hob to the gas supply system, adjusting
the taps and replacing nozzles should only be performed by a properly certified
person
3. Before beginning the connection operation make sure that the gas valve is
closed!
4. Incorrect connection and tension of the system may cause malfunction or even
damage of the hob or gas supply system.
5. The manufacturer disclaims all liability for any
The gas hob is equipped with 1/2" connector pipe. Gas supply system should be connected to
the pipe with appropriate fittings.
CONNECTING THE HOB TO NATURAL GAS SUPPLY
When connecting the hob to natural gas supply use an elbow with gasket and seal the taper
thread (at the outlet) with Teflon band. The hob may be connected to the internal supply system
with a rigid connection or a flexible metal tube. The connection method is shown in fig. 7.
