2.9 Fix the sheathed cable to (E), leaving enough cable to remove the electrical
panel from the front.
2.10 Connect the strip as shown in Figure 6.
2.11 Fit a general switch (I) independent of the appliance with a distance between
contact equal to or more than 3mm.
2.12 The machine must be earthed.
Figure 6
Figure 7
Figure 8: Technical Specifications of AD-21BDD
Model
Water
inlet
pressure
Supply
Voltage
Tank
Heating
Element
Boiler
Heating
Element
Max.
power
used
Basket
size
Cycle
duration
Tank
capacity
Rinse
water
consumed
Net
Weight
AD-
21B
DD
(200÷400
kPa)
(2÷4
Kg/cm2)
(28÷ 56
psi)
230-V-
1N
15 A 1
Phase
2 KW 2.8 KW
3.13
KW
400x400
mm
90”,
120”,
180”
15 litres
2,5
litres/rinse
39 KG
(220-240V-1N~)
am/ve=yellow-green
a= blue
m= brown
r= red
n= black
