16/11/2012
34
7. Prepare the top oven.
8. Place the top oven on the base structure.
9. Mount the side panel with the seals.
Unscrew the interior of the
3 remaining legs
12046307 ADVANCE STACKING SIDE 2
12002212 STACKING FASTENER WEDGE 4
12010090 RIVET AVINOX Ø4x10MM 16
12010163 HEXAGONAL RIVET M5 8
12008693 LOCK SPIKE 4
12023522 SEAL PORT 10/11 VERT 4
Change the leg for the
12047542 Stacking leg
