SERVICE MANUAL
ADVANCE OVENS
04/02/2020 145
DESCRIPTION
Communication error. The boiler card does not respond.
CONSEQUENCE
It is only possible to operate in Convection mode
“E27 BMF GAS CONNEX” (Only gas ovens)
DESCRIPTION
Communication error. The gas card does not respond.
CONSEQUENCE
The oven is completely disabled
17.18. ACRONYMS
A.E. Variator frequency input
A.S. Variator frequency output
ABR Rinse
CC Chamber heating
COM Common level probe
CV Steam heating
DET Detergent
DSC Descaler
HALL Gas control signal
I/D Fan motor direction of rotation (left/right)
IP Door switch
LZ Oven lighting
M/P Fan motor ignition
Ma Drainage opening
MAX Maximum level probe
Mba Wash pump
Mc Drainage closing
MIN Minimum level probe
Ms/Mb Chimney motor
PWM Gas control signal
RG: Main supply relay
TA Warning bell
TC Camera probe
TG Steam generator probe
TN Core probe
TV Steam output probe
VAC Drainage pump
VCN Condensation electrovalve
VDV Water inlet solenoid valve
VE Fan
VHM Humidification electrovalve
