·10·
Installation manual
BCSD
System
1.
GENERAL SYSTEM DIAGRAM
REF. 1711
System configurations
Low inertia 1 kW servo motors:
Motor Drive
FBS-10ADB12 BCSD-10AMA-01 Fagor axis motor, 200 V AC, 1 kW, Absolute Encoder 131072P/R,
Flat without keys, With Oil Seal.
FBS-10ADB14 BCSD-10AMA-01 Fagor axis motor, 200 V AC, 1 kW, Absolute Encoder 131072P/R,
Flat without keys, With Oil Seal, with brake (DC 24 V).
FBS-10ADB22 BCSD-10AMA-01 Fagor axis motor, 200 V AC, 1 kW, Absolute Encoder 131072P/R,
Flat with keys with screw thread, With Oil Seal.
FBS-10ADB24 BCSD-10AMA-01
Fagor axis motor, 200 V AC , 1 kW, Absolute Encoder 131072P/R,
Flat with keys with screw thread, With Oil Seal, with brake (DC 24 V).
Power cable
MPC-FBS-18-3 Motor Power cable for FBS 750 W/1 kW motor, 3 meter long.
MPC-FBS-18-5 Motor Power cable for FBS 750 W/1 kW motor, 5 meter long.
MPC-FBS-18-8 Motor Power cable for FBS 750 W/1 kW motor, 8 meter long.
MPC-FBS-18-10 Motor Power cable for FBS 750 W/1 kW motor, 10 meter long.
MPC-FBS-18-15 Motor Power cable for FBS 750 W/1 kW motor, 15 meter long.
MPC-FBS-18-20 Motor Power cable for FBS 750 W/1 kW motor, 20 meter long.
Encoder cable
EEC-FBS-A-3 Motor Encoder cable for FBS absolute motor, 3 meter long.
EEC-FBS-A-5 Motor Encoder cable for FBS absolute motor, 5 meter long.
EEC-FBS-A-8 Motor Encoder cable for FBS absolute motor, 8 meter long.
EEC-FBS-A-10 Motor Encoder cable for FBS absolute motor, 10 meter long.
EEC-FBS-A-15 Motor Encoder cable for FBS absolute motor, 15 meter long.
EEC-FBS-A-20 Motor Encoder cable for FBS absolute motor, 20 meter long.
