Installation manual
BCSD
System
GENERAL SYSTEM DIAGRAM
1.
REF. 1711
·11·
System configurations
Medium inertia 1 kW servo motors:
Motor Drive
FBM-10DDB12 BCSD-10DMA-01 Fagor axis motor, 400 V AC, 1 kW, Absolute Encoder 131072P/R,
Flat without keys, With Oil Seal.
FBM-10DDB14 BCSD-10DMA-01 Fagor axis motor, 400 V AC, 1 kW, Absolute Encoder 131072P/R,
Flat without keys, With Oil Seal, with brake (DC 24 V).
FBM-10DDB22 BCSD-10DMA-01 Fagor axis motor, 400 V AC, 1 kW, Absolute Encoder 131072P/R,
Flat with keys with screw thread, With Oil Seal.
FBM-10DDB24 BCSD-10DMA-01
Fagor axis motor, 400 V AC , 1 kW, Absolute Encoder 131072P/R,
Flat with keys with screw thread, With Oil Seal, with brake (DC 24 V).
Power cable
MPC-FBM-14-3-01 Motor Power cable for FBM 1 kW/1.5 kW motor, 3 meter long.
MPC-FBM-14-5-01 Motor Power cable for FBM 1 kW/1.5 kW motor, 5 meter long.
MPC-FBM-14-8-01 Motor Power cable for FBM 1 kW/1.5 kW motor, 8 meter long.
MPC-FBM-14-10-01 Motor Power cable for FBM 1 kW/1.5 kW motor, 10 meter long.
MPC-FBM-14-15-01 Motor Power cable for FBM 1 kW/1.5 kW motor, 15 meter long.
MPC-FBM-14-20-01 Motor Power cable for FBM 1 kW/1.5 kW motor, 20 meter long.
Encoder cable
EEC-FBM-A-3-01 Motor Encoder cable for FBM absolute motor, 3 meter long.
EEC-FBM-A-5-01 Motor Encoder cable for FBM absolute motor, 5 meter long.
EEC-FBM-A-8-01 Motor Encoder cable for FBM absolute motor, 8 meter long.
EEC-FBM-A-10-01 Motor Encoder cable for FBM absolute motor, 10 meter long.
EEC-FBM-A-15-01 Motor Encoder cable for FBM absolute motor, 15 meter long.
EEC-FBM-A-20-01 Motor Encoder cable for FBM absolute motor, 20 meter long.
