The oven has an high-performance air circulation system which gives remarkable results for
cooking and cleaning, as long as the following points are applied:
•
The oven may be fitted either underneath a work surface or in a suitable sized column
unit. Cut a hole measuring 50 mm x 50 mm in the back wall of the insert space for the
electric cable to pass through (please see diagram above).
•
Centre the oven in the unit, and make that it is at least 2 mm from any other unit beside
it.
•
The unit must be heat-resistant (or covered with heat-resistant material).
•
The oven must be disconnected from the power supply while it is being installed in the
unit.
•
For greater stability, fix the oven in the unit with 2 screws in the holes on the side
uprights (see diagram). Make a 3 mm diameter hole in the side of the unit first to prevent
the wood from splitting.
Oven
Space for Fagor 17-
litre microwave oven
Adjustment
strip
Adjustment
strip
GB
How to install your oven
