All Plumbing and Electrical Connections must be made by a qualified installer in accordance with your state and local codes!
Run Machine to verify that all electrical, water and drain hookups are correct, chemicals amount are adequate and there are no leaks!
Quick Installation Guide
LVC-21W / FI-48W / FI-64W / FI-72W
x Place Dishwasher in
permanent location
x Level Dishwasher with
4 leveling feet
x Level front to back and
side to side
First
Second
Hot Water Connection
x Min. 140˚ F (60˚C)
@ 20 psi flow
pressure
x Use 5’ flexible
water supplied hose
(Fig. 1)
x Install filter and
gasket supplied
To Wall:
Straight side + filter
x 3/4”fitting (3/4”
Garden hose
adapter supplied
if needed)
To Dishwasher:
90˚ side plus gasket
Fig. 1
Third
Level Dishwasher Drain Hook Up
x Open Drain required
x 1-1/2” minimum I.P.S.
x Use grey flex drain
supplied (Fig. 2). Clamp
it, so remains in place.
x Max. Drain Height
LVC-21W - 26-3/4”
FI-48/64W - 31-1/2”
FI-72W - 10”
Fourth
Electrical Connection
Fifth
x Remove Top and back panel to access to
terminal block (Fig. 3)
x Check Data Plate (Fig. 4) to verify Voltage
and Phase.
x Verify Terminal Block Connection. Single
Phase (Fig. 5). Three Phase (Fig.6)
x When power cord is supplied, verify the
connection has not be loosen upon shipment.
x Check Amps Consumption on Data Plate to
size breaker correctly.
x Replace the back and top panel. Careful not
pull out any wires.
x Write the Model and Serial number in the
manual and keep in a safe place.
Data Plate
(located on
the right side
lower panel)
Fig. 4
Single Phase
Three Phase
Fig. 3
Fig. 5
Fig. 6
Fig. 7
x
Dishwasher comes standard
with built-in Adjustable
Detergent and Rinse Pumps
x On the back of the Dishwasher,
locate clear tube marked as
“Detergent” and place inside
detergent container. (Fig. 7)
x The unmarked clear tube is to
be placed inside your rinse
container. (Fig. 7)
x Contact Fagor to install an
External Chemical Pump
Chemicals
Fig. 2
Use Commercial Grade,
High Temperature, Low Suds
Liquid Detergent!
