Fakir ROBERT-L - Cleaning of Dust bin and Blower; Assembly & Disassembly and Cleaning of Brush and Floor Brush

87
ROBERT-L
GB
Cleaning of Dust Bin and Blower:
1.First dump the dust, and
then clean it with dust
brush. (Refer to Figure 1)
2.Pop up the blower, and then
clean the air inlet/outlet
with dust brush. (Refer to
Figure 2 and Figure 3)
3.Don’t clean the blower in water!
4.Pop up the blower, take
out the filter, and then
clean the dust bin in
water. (Refer to Figure 4)
5.Clean the filter by
hairdryer or dust brush
(Refer to Figure 5 and
Figure 6)
6.After cleaning, you can
assemble it firmly as
before the disassembly.
9-2 Assembly & Disassembly and Cleaning of Brush and
Floor Brush: Assembly & Disassembly of Main Cleaning
Brush and Floor Brush:
1.Force the locking bar
forward and raise the
cover by right thumb, and
then raise rod of the mid
cleaning brush by your
left hand. (Refer to
Figure 1 and Figure 2)
2.Take out the Main cleaning
brush and floor brush.
(Refer to Figure 3)
3.Insert the Main cleaning
brush and floor brush
into the holes before
closing the cover in
Figure
1
Figure
2
Figure
3
Figure
4
Figure
5
Figure
6
