INSTALLATION
Check the appliance is electrically safe and gas sound when you have nished.
21
Checking the Parts:You will need the following equipment to complete the
cooker installation satisfactorily:
• Stability bracket: If the cooker is to be supplied with
gas through a flexible hose, a stability bracket or chain
MUST be fitted.
These are not supplied with the cooker but are
available at most builders’ merchants.
• Gas pressure tester/manometer.
• Flexible gas hose: Must be in accordance with the
relevant standards.
• Multimeter: For electrical checks.
You will also need the following tools:
1.
Electric drill
2. Masonry drill bit (only required if tting the cooker on a
stone or concrete oor)
3. Wall plugs (only required if tting the cooker on a stone
or concrete oor)
4. Steel tape measure
5. Cross head screwdriver
6. Flat head screwdriver
7. Spirit level
8. Pencil
9. Adjustable spanner
10. Screws for tting stability bracket
11. 4mm & 3mm Allen keys
12. 13 mm spanner or socket wrench
3 pan supports Griddle (optional)
ArtNo.000-0001 90 Pan supports
Wok cradle (optional) Grill pan & trivet
ArtNo.000-0009 Wok ring, cast
ArtNo.330-0001 - Grill pan
1 drop shelf 1 at shelf
ArtNo.324-0011 Flat & drop shelves
ArtNo.326-0002 - Energy saving shelf
Roasting tin Handyrack
ArtNo.324-0004 Roasting tin
ArtNo.324-0003 Handyrack
Tall oven shelves and shelf
supports
Plinth
ArtNo.000-0010 Tall oven shelves
ArtNo.350-0009 - 90
Classic DL plinth
