10. Technical Data
THE COOKER IS CATEGORY: Cat II
2H3+
; Cat II
2E+3+
; Cat II
2L3B/P
; Cat II
2E3B/P
; Cat II
2ELL3B/P
; Cat II
2H3B/P;
Cat II
2ELL3B/P
.
This appliance is supplied set for group H natural gas (G20 natural gas at 20 millibar). A conversion kit from NG to LP is available
for the cooker.
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening.
COUNTRY OF DESTINATION: GB, IE, FR, NL, BE, LU, DE, AT, SE, CH.
Connections
Gas (Rp ½ at rear right-hand side) Electric
Natural gas 20 mbar
230/400 V 50 HzButane 29 mbar
Propane 37 mbar
See the appliance badge for test pressures.
Dimensions
Overall height minimum 905 mm maximum 930 mm
Overall width 994 mm
Overall depth 610 mm (to front of fascia); 649 mm (over handles)
Refer to 'Positioning the Cooker'.
Ratings
Hotplate
Bypass
Screw*
Natural Gas 20 mb L.P. Gas
Injector Injector
Wok burner 57 3.5 kW
internal 78
3.5 kW (246 g/h)
internal 53
external 126 external 82
Large burner 40 3.0 kW 134 3.0 kW (210 g/h) 87
Medium burner 32 1.7 kW 109 1.7 kW (119 g/h) 68
Small burner 28 1.0 kW 75 1.0 kW (70 g/h) 51
* The valves in this cooker are tted with adjustable bypass screws. The cooker is supplied with the bypass screws set for
Natural gas. For LPG conversion the bypass screws must be screwed all the way down.
Oven Efficiency
Ovens
Main Oven Tall Oven
Forced Air
Convection
Forced Air
Convection
Maximum output @ 230 V 50 Hz 2.5 kW 2.5 kW
Energy eciency class on a scale of A (more ecient) to G (less ecient) A A
Energy consumption based on standard load 0.90 kWh 0.99 kWh
Oven volume (litres) 69 81
Size Large Large
Time to cook standard load 38 minutes 48 minutes
Surface area of the grid 1400 cm
2
1056 cm
2
Grill 2.3 kW
Maximum total electrical load at 230 V (approximate total including oven lights, oven fan, etc.): 7.4 kW.
ArtNo.105-0008 - Technical data - 90 induction - Elan
