Falcon 110 Induction - Technical Specifications and Data; Electrical Connections and Physical Dimensions; Power Ratings and Performance Data

34
8. Circuit Diagrams
Circuit Diagram: Hob
ArtNo.090-0003 - Circuit diagram - 110 induction GENERIC
ArtNo.080-0010 Proplus ceramic (hob) circuit diagram
2.3kW 2.3kW 2.3kW
1.4kW 1.4kW
CU1 CU2 CU3
To T1
MCB
To T2
MCB
To T4
MCB
To T5
MCB
To Earth
MCB
A
B
C
D F GE
br b
b
br
b
br
b
r
b
g/y
r
b
b
g/y
b
g/y
br br br b b b
g/y
b
br
br
b
r
b
br
br
Code Description
A Touchlite panel
B Distribution board
C Left-hand front control
D Left-hand rear control
E Central control
F Right-hand rear control
G Right-hand front control
Colour Code
b Blue
br Brown
bk Black
or Orange
r Red
v Violet
w White
y Yellow
g/y Green/yellow
gr Grey
