Falcon 110 Induction - 10 Technical Data

36
10. Technical Data
INSTALLER: Please leave these instructions with the User.
DATA BADGE LOCATION : Cooker back, serial number repeater badge below oven door opening.
Connections
Electric
230-240V 50Hz
Dimensions
Overall height minimum 902mm maximum 927mm
Overall width 1100mm
Overall depth 602mm (to fascia inc. splashback); 610mm (over hotplate)
Refer to 'Positioning the Cooker'.
Ratings
ArtNo.313-0002 - 110 induction hob rating
1.4kW
1.4kW
2.3kW
2.3kW 2.3kW
Ovens
Conventional Forced air convection
Oven Browning element
2.2kW 1.15kW 2.5kW
Energy eciency class on a scale
of A (more ecient) to G (less ecient)
A A
Energy consumption based on standard load 0.99kWh 0.85kWh
Usable volume (litres) 67 67
Size Large Large
Time to cook standard load 40 minutes 38 minutes
Surface area of the grid 1400cm
2
1400cm
2
Grill 2.3kW
Maximum total electrical load at 240V: 16.8kW (approximate total including oven lights, oven fan, etc.)
