TYPICAL UPS REAR PANEL LAYOUT
9. DB-9F CONTACT CLOSURE INTERFACE
This connector gives access to the UPS contact closure status interface.
Please reference page 8 of this manual for details.
10. Inlet for Input Line Cord is permenently attached to ED1500RM-1,
ED2000RM-1, ED2400RM-1 and ED2500RM-1.
11. COOLING
FANS (2)
Cooling fans draw cool air from the outside of the rear panel and
exhaust it out through slots in the UPS front panel. ALWAYS KEEP
COOLING FAN AND FRONT PANEL VENTS CLEAR OF DEBRIS. DO
NOT OPERATE THE UPS IN AN ENCLOSED SPACE.
12. TEST JUMPER
For test purposes only, do not remove.
7
