Bladsy/ Page 17
F40/120 Slasher
A0011
Item Part No. Description Qty Item Part No. Description Qty
1 H0510 Deck Painted 1200 1 41 M3171 Decal Baie Belangrik Alvorens U Die 1
2 M1203 Gearbox F40 1 42 M3168 Decal Bird FALCON Large 1
3 H1257 Disk 4-M22 PCD470 1 43 M3169 Decal Bird FALCON Small 2
4 H0402 Side panel 2 44 M3178 Decal Blade/Lem 1
5 T400760CE112F12 PTO shaft T40 760 112 F12 1 45 M3172 Decal DANGER STAY AWAY - ROTATING....... 1
6 H0601 Top mast Cat1/2 1 46 M3128 Decal F40/120 Slasher 1
7 H0212 Flap Rear 1200 1 47 M3174 Decal IMPORTANT WHEN LOADING...... 1
8 H0252 Skirt 1200 1 48 M3173 Decal Lifting hook 1
9 H0655 Clevis Right +stop 1 49 M3175 Decal PROUD TO BE SOUTH AFRICAN 1
10 H0654 Clevis Left 1 50 M3170 Decal VERY IMPORTANT BEFORE USING....... 1
11 H0702 PTO guard 1 51 M3116 Decal WARRANTY 2+2 WAARBORG............. 1
12 H0420 Skid runner 8x65 4
13 R0609 Chain GR5 9.0 1
14 H0101 Pin Hinge 1200 1
15 M0626 Lifting bracket 1
16 H1206 Ganged bolts 3/4UNFx2-1/2 2
17 M52275 Blade bolt M22-10.9 Special 4
18 H0644 Pin Btm link Cat1/2 2
19 H1812 Blade Banana 10x90x(375)-32.5 4
20 H0630 Pin Top link Cat1/2 1
21 0.140.7102.00 Nut Slotted M30x2 1
22 M62222 Nut Nyloc M22 4
23 M61919 Nut Nyloc 3/4UNF 4
24 0.139.7101.00 Washer 31x56x6 1
25 M0622 Shackle 7/16in 1.5T 2
26 M61616 Nut Nyloc M16 6
27 M81603 Washer M16x40x3 2
28 M41650 Bolt M16x50HT 6
29 M40815 Bolt M8x16HT 4
30 M1416 Split pin B5x60 1
31 FLP11 Lynchpin 11mm 3
32 M91604 Washer Spring M16 6
33 H71613 Bush 16x25x13 2
34 M91002 Washer Spring M10 21
35 LF14086700269 Plug Breather 1/2BSP 1
36 M11025 Bolt+nut M10x25HT 18
37 M11640 Bolt+nut M16x40HT 12
38 M21030 Plough bolt+nut M10x30HT 24
39 M3003 Serial plate 1
40 M3187 Decal ATTENTION If your tractor is .... 1
