Bladsy/ Page 47
Falcon F80 Gearbox
H1400A
Item Part No. Description Qty
1 M1413 Bearing 390 1
2 M1412 Bearing 394A 1
3 H1414 Gear Bevel Z28/z6 1
4 H82802 Washer 29x50x4 1
5 M1415 Nut Slotted 1-1/8in 1
6 M41225 Bolt M12x25HT 12
7 M81201 Washer Star M12 8
8 H1410 Input cover F80 1
9 M1434 Shim Input 0.1 Plastic A/R
10 M1411 Gasket Input F80 1
11 H1409 Shaft Input 1-3/8 Z6 1
12 M1408 Bearing LM29710 1
13 M1407 Bearing LM29749 1
14 M1404 Seal Lip 187275 1
15 M1406 O-ring 34.5x3.5 1
16 H1405 Seal Lip 1
17 M1403 Washer Tabbed KM06 1
18 H1402 Locknut M36x2.0 1
19 M1439 Plug + Dipstick 1
20 H1420A Cover Gearbox F80 1
21 M1421A Gasket Top F80 1
22 H1417A Housing F80 1
23 H1428 Dust cover 1
24 M41045 Bolt M10x45HT 2
25 M31007 Nut M10 2
26 M1422 Nut Slotted 1-1/4in 1
27 M1446 Washer Hard 32x50x2 1
28 H1423 Gear Beval Z15/z10 1
29 M1441 Shim 38x60x0.5 A/R
30 M1440 Shim 38x60x0.25 A/R
31 M1442 Shim 38x60x1.0 A/R
32 M1424 Bearing 3577 1
33 M1425 Bearing 3525 1
34 H1429 Retainer Domed 1
35 M1430 Bearing 28920 1
36 M1431 Bearing 28985 1
37 M1432 Seal Lip 300400 2
38 M1433 Seal Felt 75x100x12 1
39 H1426 Shaft Output F80 1
40 M1416 Split pin B5x60 2
To Next Page
