Bladsy/ Page 41
F80/180/4 Slasher
A0034/4
Item Part No. Description Qty Item Part No. Description Qty
1 H0531 Deck Painted 1800 1 41 M3174 Decal IMPORTANT WHEN LOADING...... 1
2 H1400A Gearbox F80 1 42 M3173 Decal Lifting hook 1
3 H1260 Disk 4-M22 PCD650 1 43 M3175 Decal PROUD TO BE SOUTH AFRICAN 1
4 H0406 Side panel 2 44 M3170 Decal VERY IMPORTANT BEFORE USING....... 1
5 H0602 Top mast Cat2 1 45 M3117 Decal WARRANTY 2+3 WAARBORG............. 1
6 T600960CE112F22 PTO shaft T60 960 112 F22 1 46 M8400 Operators manual Slashers 1
7 H0207 Flap Rear 1800 1
8 H0206 Flap Rear 1800 1
9 H1810 Blade Banana 10x90x(585)-32.5 4
10 H0702 PTO guard 1
11 H0103 Pin Hinge 1800 1
12 H1448 Ganged bolts 3/4UNFx2-1/2 2
13 H0422 Skid runner 8x90 4
14 H0643 Pin Btm link Cat2 2
15 M52275 Blade bolt M22-10.9 Special 4
16 H0632 Pin Top link Cat2 1
17 R0611 Chain GR5 10.0 1
18 M62222 Nut Nyloc M22 4
19 M61919 Nut Nyloc 3/4UNF 4
20 M0622 Shackle 7/16in 1.5T 2
21 H71617 Bush 16x25x17 2
22 M31612 Nut M16 6
23 M61616 Nut Nyloc M16 2
24 M81603 Washer M16x40x3 2
25 M41655 Bolt M16x55HT 2
26 M41650 Bolt M16x50HT 6
27 FLP11 Lynchpin 11mm 3
28 M91604 Washer Spring M16 12
29 M91002 Washer Spring M10 17
30 M11025 Bolt+nut M10x25HT 10
31 M11640 Bolt+nut M16x40HT 24
32 M21030 Plough bolt+nut M10x30HT 24
33 M3003 Serial plate 1
34 M3187 Decal ATTENTION If your tractor is .... 1
35 M3171 Decal Baie Belangrik Alvorens U Die 1
36 M3168 Decal Bird FALCON Large 1
37 M3176 Decal Bird Falcon Meduim 2
38 M3178 Decal Blade/Lem 1
39 M3172 Decal DANGER STAY AWAY - ROTATING....... 1
40 M3149 Decal F80/180/4 Slasher 1
