Bladsy/ Page 19
F40/150 Slasher
A0013
Item Part No. Description Qty Item Part No. Description Qty
1 H0511 Deck Painted 1500 1 41 M3187 Decal ATTENTION If your tractor is .... 1
2 M1203 Gearbox F40 1 42 M3171 Decal Baie Belangrik Alvorens U Die 1
3 H0404 Side panel 2 43 M3168 Decal Bird FALCON Large 1
4 H0603 Top mast Cat1/2 1 44 M3176 Decal Bird Falcon Meduim 2
5 T600960CE112F22 PTO shaft T60 960 112 F22 1 45 M3178 Decal Blade/Lem 1
6 H0202 Flap Rear 1500 1 46 M3172 Decal DANGER STAY AWAY - ROTATING....... 1
7 H1241 Disk 4-M22 PCD650 1 47 M3130 Decal F40/150 Slasher 1
8 H0253 Skirt 1500 1 48 M3174 Decal IMPORTANT WHEN LOADING...... 1
9 H0655 Clevis Right +stop 1 49 M3173 Decal Lifting hook 1
10 H0654 Clevis Left 1 50 M3175 Decal PROUD TO BE SOUTH AFRICAN 1
11 H0702 PTO guard 1 51 M3170 Decal VERY IMPORTANT BEFORE USING....... 1
12 H0102 Pin Hinge 1500 1 52 M3116 Decal WARRANTY 2+2 WAARBORG............. 1
13 M0626 Lifting bracket 1
14 H0422 Skid runner 8x90 4
15 H1206 Ganged bolts 3/4UNFx2-1/2 2
16 H0645 Pin Btm link Cat2/1 2
17 M52275 Blade bolt M22-10.9 Special 4
18 H0633 Pin Top link Cat2/1 1
19 H1801 Blade Banana 10x90x(440)-32.5 4
20 R0611 Chain GR5 10.0 1
21 0.140.7102.00 Nut Slotted M30x2 1
22 M62222 Nut Nyloc M22 4
23 M61919 Nut Nyloc 3/4UNF 4
24 0.139.7101.00 Washer 31x56x6 1
25 M0622 Shackle 7/16in 1.5T 2
26 H71617 Bush 16x25x17 2
27 M61616 Nut Nyloc M16 6
28 M81603 Washer M16x40x3 2
29 M41655 Bolt M16x55HT 2
30 M41650 Bolt M16x50HT 4
31 M40815 Bolt M8x16HT 4
32 M1416 Split pin B5x60 1
33 FLP11 Lynchpin 11mm 3
34 M91604 Washer Spring M16 6
35 M91002 Washer Spring M10 21
36 LF14086700269 Plug Breather 1/2BSP 1
37 M11025 Bolt+nut M10x25HT 18
38 M11640 Bolt+nut M16x40HT 12
39 M21030 Plough bolt+nut M10x30HT 24
40 M3003 Serial plate 1
