Falcon G2102 C Installation And Servicing Instructions

1.5 ELECTRICAL SUPPLY
Installation, periodic testing, repair and fixed wiring connections should only be
undertaken by a competent electrician.
The oven is equipped with a length of 3-core flexible cord for connecting to an electrical supply. A
standard 13 amp socket outlet can be used, in which case the plug must be fitted with a 3 amp fuse.
If the supply is through a distribution fuse box, it must be via a fuse having a maximum rating of 5
amps.
We recommend supplementary electrical protection with the use of a residual current device (RCD).
1.6 WATER SUPPLY
Not applicable to these appliances.
1.7 TOTAL GAS RATES -
Natural I
2
H and Propane Gas I
3
P
Model
kW (net)
Btu/hr (gross)
G2102 C
49.8
187,000
G2112 C
18
67,600
G2112 C/2
36
135,100
1.7.1 Individual Burner Ratings -
Natural I
2
H and Propane Gas I
3
P
Burner type
kW (net)
Btu/hr (gross)
Open Top (x6)
5.3
20,000
Oven
18
67,600
Oven Pilot/Ignition
0.25
940
1.8 INJECTOR DIAMETERS - Natural I
2
H & Propane Gas I
3
P
Natural
Gas I
2
H
Propane
Gas I
3
P
Open top
Ø1.92mm
Ø1.2mm
Oven
Ø3.3mm
Ø2.2mm
Oven Pilot
G29.2
G24.1
1.9 GAS PRESSURE
Supply Pressure
Burner Operating Pressure
Nat I
2
H
Prop I
3
P
Nat I
2
H
Prop I
3
P
mbar
20
37
15
37
1.10 BURNER ADJUSTMENTS
1.10.1 Burner Aeration
All burners have fixed aeration, and no modifications to the size of air-entry should be attempted.
1.10.2 Open Top Gas Tap – Low Position Screw Details
The Open Top Low Position flow to burner is governed by the size of the fixed hole in Low Position
Screw as detailed below: - The screw is located to Right hand side of the gas tap spindle.
Turndown Flow
1.1kW
Natural Gas I
2
H
No.76
Propane Gas I
3
P
No.51
