8
OPTIONAL SLIDE MOUNTING KIT (SGRMKIT)
An slide mounting kit option is available from Falcon Electric. The part number for the kit
is SGRMKIT and may be installed on any rackmount UPS and battery bank referenced in
this manual. As all 2-3kVA models consist of seperate UPS and battery bank modules, two
slide mounting kits are required , one for each module. All 1kVA UPS models will only
require one slide kit.
Slide Inst
allation Instructions
NOTE: Only use the referenced lenght screws when mouning the slides to the
sides of the UPS and battery module or UPS damage may result.
1. Install the slides per the following diagram.
Slide Mounting Details
1. Slide, General Devices #CLB-203-16 Qty. 2
2. Slide Mounting Bracket (Short) Qty. 2
3. SLide Mounting Bracket (Long) Qty. 2
4. Screws, 8-32 x 3/16” Phillips Pan Head Qty. 8 (DO NOT USE LONGER SCREWS)
