1. Drill holes in the floor surface. For this, you can use the included drill template. Ensure at least 130 mm of free
space behind the iM.60. This is the space required to disassemble the cover.
2. Place the iM.60 on a flat subsurface with the screw fittings on the bottom.
If the iM.60 cannot be placed on a flat subsurface, you can use the included shims (0.5 mm and 1.0 mm
thickness).
3. Seal the screw fittings with grout to prevent penetration of moisture, dust and/or corrosive gases.
2.2 Mounting the coercion roller
