Fancom iM.60 - Mounting the Steel Cable on the Coercion Roller; Mounting the Strap Drum and Strap

Gnd
4
g
2.3 Mounting the steel cable on the coercion roller
Ensure that you have the steel cable on the correct side and that you have the prope
r direction of rotation
for coiling up the steel cable.
1. Pull the steel cable through the hole in the flange.
2. Mount the retaining clip on the end of the steel cable.
3. Wrap the steel cable around the flange at least once.
2.4 Mounting the strap drum and strap
Ensure that you have the strap on the correct side and that you have the proper direction of rotation for
coiling up the strap.
