7. Appendix 1: Overview WebLinkBox board
Component Description Colour
LED 1 FNet Transmit Red
LED 2 IO-net or Current loop Red
LED 3 Ethernet active Yellow
LED 4 Ethernet link Green
LED 5 Supply voltage present Red
LED 6 Run led Green
LED 7 UDP communication Yellow
