** Insert FINISH CODES (Refer to fan model number located on downrod support)
Parts List
Model #FP8511**
Before discarding packaging materials, be certain all parts have been removed.
1
2
3
4
5
6
Canopy Screw Cover Assembly
AP255BL
ADR1-45**
PG154**
AP260**
APPCP1404**
AMA8511**
AP851103CL
AP851102NI
AP851105
7
Switch Housing Assembly
Light Plate Assembly
8
9
AP845810LED Assembly
Light Shade
Light Kit Wire Cover with Screw
Steel Cap
Hand-held Remote
Receiver
10
11
12
13
14
15
P851109OP
AP845813BL
P851107**
TR500
RCCA05005000
Blade Set
Wire Connectors (4)
Hardware Bag Containing:
Motor Coupling Cover Assembly
Motor Assembly
Downrod/Hanger Ball Assembly
Ceiling Canopy
Ref. # Description Part #
Hanger Bracket Assembly
Safety Cable Kit
16
HDWFP8511**
3/16˝-24 Serrated Head Screws (10)
Blade Mounting Hardware Bag Containing:
Blade Plates (3)
How To Order Parts
When ordering repair parts, always give the
following information:
• Fan Model Number
• Part Number
• Part Description
• Date Code
Contact techsupport@fanimation.com or
call 1.888.567.2055 for repair parts.
