Faraday RSE-300 - Slave Operation with Dual Sync Control Module; Figure 4-10. Slave Operation with Dual Sync Control Module

15073 OWNER’S MANUAL
447179 Issue 1 Rev. A 26
Figure 4-10. Fire Alarm Control Unit NACs activating more than one 15073 set for Slave Operation using
the 5406 Dual Sync Control Module (Four wires required between units)
Note:
The configuration in Figure 4-9 or Figure 4-10 must be used, when synchronization of
Sync Strobes/Horns is required between NACs of different 15073s.
Output 1 Output 2 Output 3
Output 4
NAC 1 (Non-Silencable)
Fire Alarm
Control Unit
Input 1
120 VAC
1
2
3
120 VAC
2
1
3
Input 1
Output 1
Output 2
Output 3
Output 4
Dual Sync
Control Module
NAC 2 (Non-Silencable)
NAC 3 (Silencable)
Input 1
120 VAC
3
1
2
Output 1
Output 2
Output 3
Output 4
120 VAC
Input 1
3
2
1
Output 1
Output 2
Output 3
Output 4
Trouble
N/C
Trouble
N/C
Trouble
N/C
