Faraday RSE-300 - Jumper Settings Configuration; NAC 1-2 Configuration Jumpers (J4, J5); NAC 3-4 Configuration Jumpers (J7, J8); Ground Detection Configuration Jumper (J9)

15073 OWNER’S MANUAL
447179 Issue 1 Rev. A 34
5.2 JUMPER SETTINGS
Factory settings are shown.
Note: Changing settings for J4-J8 also affect the settings for SW1 DIP switches 1-3.
J4 – NAC 1-2 Configuration (J5 must be set the same)
• 1 Class B
• 2
• 3 Class A
J5 – NAC 1-2 Configuration (J4 must be set the same)
• 1 Class B
• 2
• 3 Class A
J7 – NAC 3-4 Configuration (J8 must be set the same)
• 1 Class B
• 2
• 3 Class A
J8 – NAC 3-4 Configuration (J7 must be set the same)
• 1 Class B
• 2
• 3 Class A
J9 – Ground Detection Configuration
• 1 Enabled
• 2
• 3 Disabled
J10 – Battery Charger Configuration
• 1 Enabled
• 2
• 3 Disabled
