Faraday RSE-300 - Four-Wire Smoke and Heat Detectors

15073 OWNER’S MANUAL
447179 Issue 1 Rev. A 42
7.2.4 Four-Wire (Separately Powered) Smoke and Heat
Detectors
Faraday
Detector
w/Base
Mfg. Detector w/Base Maximum
Standby
Current
Maximum
Alarm
Current
Notes
Air Products & Controls
9269 RW-DC-N 0.081m 115mA Must use EOL Relay
9270 RW-DC-P 0.110m 115mA Must use EOL Relay
Apollo Fire Detectors
9260 w/9266 55000-350 w/45681-227 0.130m 100mA Must use EOL Relay
9261 w/9266 55000-250 w/45681-227 0.081m 100mA Must use EOL Relay
9264 w/9266 55000-153 w/45681-227 0.086m 100mA Must use EOL Relay
9274 w/9266 55000-152 w/45681-227 0.096m 100mA Must use EOL Relay
9259 w/9266 55000-150 w/45681-227 0.086m 100mA Must use EOL Relay
9221 w/9266 55000-151 w/45681-227 0.086m 100mA Must use EOL Relay
9222 w/9266 55000-380 w/45681-227 0.205m 100mA Must use EOL Relay
System Sensor
9337 1112/24 0.050mA 25mA Must use EOL Relay
9338 2112/24 0.050mA 25mA Must use EOL Relay
9339 2112/24T 0.050mA 25mA Must use EOL Relay
9340 2112/24TSRB 15mA 45mA Must use EOL Relay
9358 w/9362 1451 w/B402B 0.120mA 36mA Must use EOL Relay
9359 w/9362 2451 w/B402B 0.120mA 36mA Must use EOL Relay
9360 w/9362 2451TH w/B402B 0.120mA 36mA Must use EOL Relay
9447 w/9362 5451 w/B402B 0.120mA 36mA Must use EOL Relay
9421 w/9362 4451HT w/B402B 0.120mA 36mA Must use EOL Relay
9183 w/9186 2151 w/B112LP 0.120mA 36mA Must use EOL Relay
9184 w/9186 1151 w/B112LP 0.120mA 36mA Must use EOL Relay
Notes:
1. For specific wiring and installation information, read the instructions provided with each device.
2. Each 9273 EOL Relay requires 15 mA. standby current.
