15073 OWNER’S MANUAL
447179 Issue 1 Rev. A 21
44 SAMPLE APPLICATIONSSAMPLE APPLICATIONS
The drawings in this section show various configurations, including daisy-chaining.
4.1 Notification Appliance Power Applications
Figure 4-1. Input 1 activates All Four Outputs and Input 2 not used
Figure 4-2. Input 1 activates All Four Outputs and Input 2 used to silence Sync Horns
120 VAC
Input 1
Unit
Fire Alarm
Control
120 VAC
Input 1
Unit
Fire Alarm
Control
Input 2
