Mounting of frame bottom and door speaker
(amplifier).
Top fixing of the panel.
Alignment of the panel.
Hood covers
Dismounting of the frame top side from the
rain shelter.
Fixing of the hood cover between the back
box and the module frame.
Rain shelter
Modules insertion and wall fixing of rain shel-
ter.
Mounting of the frame top to the rain shelter.
