FATEK CBEH-2A User Manual

11
⑩ ADC0: First voltage input ( 0 ~ 10V )
*1
⑪ ADC0: First current input ( 0 ~ 20mA )
*1
⑫ ADC1: Second voltage input ( 0 ~ 10V )
*1
⑬ ADC1: Second current input ( 0 ~ 20mA )
*1
⑭ ADC Ground
Note
*1
: The same ADC input set does not allow concurrent voltage and current input
1.6 Companionate Softwares
 Ether Config
An application that works with the FBs-CBEH series expansion board provides a
window-based configuration software, used to set the module’s basic settings,
password protection and firmware update etc. Please refer to Chapter 3.1 for
detailed explanation.
 Easy Web Designer
The Easy Web Designer has the following two functions:
1. Create customized web pages
