FATEK CBEH-2A - Network Parameters

14
Email Sending
Register
Description
D3961
(CPU Written
*1
)
Email command code
Setting value
Status
0x3370
Execute Email sending, when completed, value
zero must be entered.
D3962
(CPU Written
*1
)
The message number of the Email to be sent
D3963
Email send status
Content value
Status
0
Standby
1
Executing
2
Send complete
10
Email code error
11
Send failed
12
Construction data error
ADC Digits
D3964
ADC0
D3965
ADC1
Network Parameters
Register
Description
D3978~D3981
Primary domain name server(DNS)IP
D3982~D3985
Secondary domain name server (DNS)IP
D3986
The first decimal number of the local network mask (MY_MASK.A)
D3987
The second decimal number of the local network mask (MY_MASK.B)
D3988
The third decimal number of the local network mask (MY_MASK.C)
D3989
The fourth decimal number of the local network mask (MY_MASK.D)
D3990
(CPU Written
*1
)
network parameter setting mode
=0x4951, network parameters determined by register contents
=0x4960, acquired using DHCP
=other value, determined by the contents of the configuration tool
D3991
The first decimal number of the board network address (MY_IP.A)
D3992
The second decimal number of the board network address (MY_IP.B)
D3993
The third decimal number of the board network address (MY_IP.C)
D3994
The fourth decimal number of the board network address (MY_IP.D)
D3995
The first decimal number of the router network address (ROUTER_IP.A)
D3996
The 2’nd decimal number of the router network address (ROUTER_IP.B)
D3997
The 3’rd decimal number of the router network address (ROUTER_IP.C)
D3998
The 4’th decimal number of the router network address (ROUTER_IP.D)
D3999
Board’s serial number (S/N)
Note 1: Example of network address (IP) 192.168.2.1, first code: 192, second code: 168, third code: 2,
fourth code: 1.
Note 2: When D3990 is not 0x4951, after started up the contents of D3978~D3989 and D3991~D3998
will display the actual setting value.
Note 3: D3964~D3976 reserved.
