H5-4
5.3 Residual Capacity of Main/Expansion Unit & Current Consumption of Expansion
Module
Besides its own circuits usage, the residual capacities of three sets of built-in power supply of main/expansion unit are
big enough for other expansion modules usage. In addition, the expansion power (FB
S-EPW) module can also provides
the power for expansion modules usage. As each model of the main/expansion unit has AC/DC power or modules, it has
different residual capacity, various models of expansion modules also consume different amounts of current. In practice,
one has to consider the match between the two to avoid overload in any of the three sets of output power. In the
following, the worst case of the available residual capacity in each main/expansion unit and the maximum power
consumption of expansion modules are described below spare.
5.3.1 Residual Capacity of Main/Expansion Unit
Extra Capacity
Model
Output Power
5VDC(logic circuit) 24VDC(output circuit) 24VDC(input circuit)
-output communication block
or expansion cable-
-output expansion cable- -output terminal block-
AC
P
O
W
E
R
Main
Unit
FB
S-10/14MA
300mA － 340mA
FBS-20MA
753 mA 335mA 310mA
FBS-24MA
722 mA 325mA 295mA
FBS-32MA
712 mA 315mA 262mA
FBS-40MA
688 mA 295mA 244mA
FBS-60MA
644 mA 255mA 190mA
FBS-10/14MC
300 mA － 340mA
FBS-20MC
753 mA 335mA 310mA
FBS-24MC
722 mA 325mA 295mA
FBS-32MC
712 mA 315mA 262mA
FBS-40MC
688 mA 295mA 244mA
FBS-60MC
644 mA 255mA 190mA
FBS-20MN
710mA 310mA 325 mA*
FBS-32MN
670mA 297mA 280 mA*
FBS-44MN
627 mA 276 mA 250 mA*
Expansion
Unit
FB
S-24XY-◎
948 mA 350mA 337mA
FBS-40XY-◎
918 mA 320mA 292mA
FBS-60XY-◎
880 mA 280mA 238mA
DC
P
O
W
E
R
Main
Unit
FBS-10/14MA-D24
300mA － 270mA
FBS-20MA-D24
753mA Total295mA
FBS-24MA-D24
722mA Total270mA
FBS-32MA-D24
712mA Total227mA
FBS-40MA-D24
688mA Total 189mA
FBS-60MA-D24
644mA Total 95mA
FBS-10/14MC-D24
300mA － 270mA
FBS-20MC-D24
753mA Total 295mA
FBS-24MC-D24
722mA Total 270mA
FBS-32MC-D24
712mA Total 227mA
FBS-40MC-D24
688mA Total 189mA
FBS-60MC-D24
644mA Total 95mA
