1.4 List of FBs-PLC Models
Module Name Specifications
Main Units
Basic
Main Units
FBs-10MA◇∆–◎–C
6 points 24VDC digital input (2 points high speed 100KHz, 2 points medium speed 20KHz, 2 points
medium speed total 5KHz); 4 points relay or transistor output (2 points high speed 100KHz, 2 points
medium speed 20KHz); 1 RS232 or USB port(expandable up to 3); I/O is not expandable
FBs-14MA◇∆–◎–C
8 points 24VDC digital input (2 points high speed 100KHz, 2 points medium speed 20KHz, 4 points
medium speed total 5KHz); 6 points relay or transistor output (2 point high speed 100KHz, 4 points
medium speed 20KHz); 1 RS232 or USB port(expandable up to 3); I/O is not expandable
FBs-20MA◇∆–◎–C
12 points 24VDC digital input (2 points high speed 100KHz, 4 points medium speed 20KHz, 6 points
medium speed total 5KHz); 8 points relay or transistor output (2 points high speed 100KHz, 6 points
medium speed 20KHz); 1 RS232 or USB port(expandable up to 3)
FBs-24MA◇∆–◎–C
14 points 24VDC digital input (2 points high speed 100KHz, 6 points medium speed 20KHz, 6 points
medium speed total 5KHz); 10 points relay or transistor output (2 points high speed 100KHz, 6 points
medium speed 20KHz); 1 RS232 or USB port(expandable up to 3)
FBs-32MA◇∆–◎–C
FBs-32MB◇∆–◎–C
20 points 24VDC digital input (2 points high speed 100KHz, 6 points medium speed 20KHz, 8 points
medium speed total 5KHz); 12 points relay or transistor output (2 points high speed 100KHz, 6 points
medium speed 20KHz); 1 RS232 or USB port(expandable up to 3); (MB is detachable terminal block)
FBs-40MA◇∆–◎–C
FBs-40MB◇∆–◎–C
24 points 24VDC digital input (2 points high speed 100KHz, 6 points medium speed 20KHz, 8 points
medium speed total 5KHz); 16 points relay or transistor output (2 points high speed 100KHz, 6 points
medium speed 20KHz); 1 RS232 or USB port(expandable up to 3); (MB is detachable terminal block)
FBs-60MA◇∆–◎–C
FBs-60MB◇∆–◎–C
36 points 24VDC digital input (2 points high speed 100KHz, 6 points medium speed 20KHz, 8 points
medium speed total 5KHz); 24 points relay or transistor output (2 points high speed 100KHz, 6 points
medium speed 20KHz); 1 RS232 or USB port(expandable up to 3); (MB is detachable terminal block)
Advanced
Main Units
FBs-10MC◇∆–◎
6 points 24VDC digital input (2 points high speed 200KHz, 2 points medium speed 20KHz, 2 points
medium speed total 5KHz); 4 points relay or transistor output (2 points high speed 200KHz, 2 points
medium speed 20KHz); 1 RS232 or USB port (expandable up to 5); built-in RTC; I/O is not expandable
FBs-14MC◇∆–◎
8 points 24VDC digital input (2 points high speed 200KHz, 2 points medium speed 20KHz, 4 points
medium speed total 5KHz); 6 points relay or transistor output (2 points high speed 200KHz, 4 points
medium speed 20KHz); 1 RS232 or USB port (expandable up to 5); built-in RTC; I/O is not expandable
FBs-20MC◇∆–◎
12 points 24VDC digital input (4 points high speed 200KHz, 2 points medium speed 20KHz, 6 points
medium speed total 5KHz); 8 points relay or transistor output (4 points high speed 200KHz, 4 points
medium speed 20KHz); 1 RS232 or USB port (expandable up to 5); built-in RTC; detachable terminal block
FBs-24MC◇∆–◎
14 points 24VDC digital input (4 points high speed 200KHz, 4 points medium speed 20KHz, 6 points
medium speed total 5KHz); 10 points relay or transistor output (4 points high speed 200KHz, 4 points
medium sped 20KHz); 1 RS232 or USB port (expandable up to 5); built-in RTC; detachable terminal block
FBs-32MC◇∆–◎
20 points 24VDC digital input (6 points high speed 200KHz, 2 points medium speed 20KHz, 8 points
medium speed total 5KHz); 12 points relay or transistor output (6 points high speed 200KHz, 2 points
medium speed 20KHz); 1 RS232 or USB port (expandable up to 5); built-in RTC; detachable terminal block
FBs-40MC◇∆–◎
24 points 24VDC digital input (6 points high speed 200KHz, 2 points medium speed 20KHz, 8 points
medium speed total 5KHz); 16 points relay or transistor output (6 points high speed 200KHz, 2 points
medium speed 20KHz); 1 RS232 or USB port (expandable up to 5); built-in RTC; detachable terminal block
FBs-60MC◇∆–◎
36 points 24VDC digital input (8 points high speed 200KHz, 8 points medium speed total 5KHz); 24 points
relay or transistor output (8 points high speed 200KHz); 1 RS232 or USB port (expandable up to 5);
built-in RTC; detachable terminal block
NC Positioning
Main Units
FBs-20MN◇∆–◎
2 sets (1 axis) 920KHz 5VDC digital differential input, 10 points 24VDC digital input (4 points high speed
200KHz, 6 points medium speed total 5KHz); 2 sets (1 axis) 920KHz 5VDC digital differential output, 6
points relay or transistor output (average high speed 200KHz); 1 RS232 or USB port (expandable up to 5);
built-in RTC; detachable terminal block
FBs-32MN◇∆–◎
4 sets (2 axes) 920KHz 5VDC digital differential input, 16 points 24VDC digital input (4 points high speed
200KHz, 8 points medium speed total 5KHz); 4 sets (2 axes) 920KHz 5VDC digital differential output, 8
points relay or transistor output (4 points high speed 200KHz); 1 RS232 or USB port (expandable up to 5);
built-in RTC; detachable terminal block
FBs-44MN◇∆–◎
8 sets (4 axes) 920KHz 5VDC digital differential input, 20 points 24VDC digital input (8 points medium
speed total 5KHz); 8 sets (4 axes) 920KHz 5VDC digital differential output, 8 points relay or low speed
transistor output; 1 RS232 or USB port (expandable up to 5); built-in RTC; detachable terminal block
Right Side Expansion Modules
Expansion Power
Supply
FBs-EPW–AC/D24
Power supply of 100~240VAC or 24VDC input for expansion module; 3 sets output power with 5VDC,
24VDC, and 24VDC, 14W capacity
DIO
Expansion Units
FBs-24XY◇–◎
14 points 24VDC digital input, 10 points relay or transistor output, built-in power supply
FBs-40XY◇–◎
24 points 24VDC digital input, 16 points relay or transistor output, built-in power supply
FBs-60XY◇–◎
36 points 24VDC digital input, 24 points relay or transistor output, built-in power supply
DIO Expansion
Modules
FBs-8X
8 points 24 VDC digital input
FBs-8Y◇
8 points relay or transistor output
FBs-8XY◇
4 points 24VDC digital input, 4 points relay or transistor output
FBs-16Y◇
16 points relay or transistor output
FBs-16XY◇
8 points 24VDC digital input, 8 points relay or transistor output
FBs-20X
20 points 24VDC digital input
FBs-24XY◇
14 points 24VDC digital input, 10 points relay or transistor output
FBs-40XY◇
24 points 24VDC digital input, 16 points relay or transistor output
FBs-60XY◇
36 points 24VDD digital input, 24 points relay or transistor output
FBs-24X
24 points high-density 24VDC digital input, 30 pins header with latch
FBs-24YT/J
24 points high-density transistor SINK(T) or SOURCE(J) output (0.1A max.)，30 pins header with latch
