FAY-002
2-20
FAY-002 BIOS Programmable connector
PIN 1
SPI
GND
SPI_CLK_F
SPI_SI_F
(NC)
+V3.3SPI
SPI_CS0#_F
SPI_SO_F
(NC)
11. BIOS programmable connector (8-pin SPI)
UsethisconnectortoashtheBIOSROM.
124. Digital I/O connector (10-pin DIO1)
Thisconnectorincludes8I/Olines(In/Outprogrammable).AlloftheDigital
I/OlinesareprogrammableandeachI/Opincanbeindividuallyprogrammed
tosupportvariousdevices.
FAY-002 Digitial I/O connector
PIN 1
DIO1
+5VS
DIO_P#7
DIO_P#5
DIO_P#3
DIO_P#1
GND
DIO_P#8
DIO_P#6
DIO_P#4
DIO_P#2
