FBD 563 - Table of Contents

Table of Contents
2
FBD 56X specifications…….5
Typical unit setup …………..7
Product flow path …………..8-11
Header assembly…………..12-14
Expansion tank………….….15
Critical settings………….…..16
Beater Motor/Valves………..17-18
Electrical component ….…..19-20
Board descriptions………….21-23
Refrigeration…………………24-26
Keypad operation……………27-29
Menu structure………………30
Menu functions………………31-51
Thaw/Freeze…………………52
Voltage offset adjustment….53-56
Initial start up and freeze…….56-58
E-prom replacement………….59
Status light definition…………60
Electrical diagrams…………..61-62
Troubleshooting
boards……………..……….63-66
Transducers…..……………67
CO
2
and solution solenoid..68
LCD messages……………...69-72
Preventive maintenance……73-74
Remote condenser………….75-79
Product warranty…………….80-84
