FBD 563 - LCD Messages

LCD Messages
52
DISPLAY
MEANING
1 HOT PRODUCT SHUTDOWN
Comp on with both temp sensors are @ 90F or below
-20° for 3min and 20sec
2 Cmp ran too long-OFF
Comp on for longer than 90 mins
3 DEFPRO/RUNPRO
Product out condition for more than 15 min.
4 Stop BTR LongPrd out
5 RunPmx
Tank pressure at 55psig for more than 15 min
6 Stop BTR Long PMAX
Stop motor due to long P
-max
7 InTmpE / ERRORi
Failed inlet temperature
8 RTempE / ERRORr
Failed return temperature
9 TnkPsi / ERRORz
During filling tank pressure transducer stays a 0 psi for 30 sec
10 SFilEr / ERRORs
During filling tank pressure transducer stays below Refill value for 1 min
11 BTR-LO / ERRORl
Beater% drops below 200 or 300, and triggers a defrost cycle
12 BTR-HI /ERRORh
Beater% is above 1200.
13 CO2out/CO2OUT
CO2 pressure is below 35 psi.
14 H2Oout/H2oOUT
Water pressure is below 35 psi.
15 SyrOut/SYROUT
Syrup pressure is below 35 psi.
16 DFROST
Machine is in defrost mode
17 SLEEP
Machine is in sleep mode
18 WAIT
Machine is in First Freeze process
19 READY
Machine is in ready mode
20 RunOff
Machine is in OFF mode
21 CmpRun
Compressor is ON
