FBD 563 - Electrical System

Electrical System
28
Lower Board
Main PC Board
Auxiliary board
Contactor
Run
Capacitor
Relay Board
EEPROM
Memory/Timer Chip
LCD Display
Electrical System
Model 562 563 564
Eeprom 1 1 1
Relay Board 1 1 1
Main PC 1 1 1
Auxiliary Board 0 0 1
Clock/Timer Board 1 1 1
LCD Display 1 1 1
Lower Board 1 1 2
Contactor 1 1 1
Transformer 1 1 1
Compressor Run Cap
1 1 1
Transformer
