With this function, the maintenance technician can
quickly judge whether the relative position of the
camera and the target is correct or measure in the mode
without vehicle data
Device private settings, global system settings, shop
information settings, etc
4 5D Four-wheel alignment system operation process
Before testing the wheel, the target should be monitored to ensure that the target is
complete clear within the camera viewable range. After the target monitoring is completed,
the vehicle pushing compensation and the caster measurement can be performed. If the
measured result does not meet the requirements of the standard database, the
corresponding adjustment should be made. After the adjustment is completed, a test run
should be carried out to check whether the abnormal condition of the vehicle is eliminated.
If the standard is not met, the measurement should be re-adjusted. The functions and
operation methods of FCAR 5D four-wheel alignment system will be specifically
introduced below.
The flow chart is as follows:
