type.
Figure 6.2-1 Target type setting
Table 1：
Target type
Physical map
Applicable platform
Small scissors
target
Small scissor installation scheme,
large scissor installation scheme
Double column
target
Double-column installation,
four-column installation
Big target 5*5
Not applicable
Not applicable
Small target 5*5
Not applicable
Not applicable
Tip: For the installation plan of each platform, please refer to the “2.3 5D
Four-wheel alignment system installation method” section of this manual.
