FCAR FD505 Wheel Alignment System User Manual
7
Technical parameter:
Measure item
Measure accuracy
Measure range
Camber angle
±0.01°
±8°
Caster angle
±0.03°
±19°
Front wheel inclination angle
±0.02°
±19°
Toe
±0.01°
±2°
Rear wheel thrust angle
±0.02°
±2°
Rear wheel axle deflection
±0.02°
±2°
Wheelbase difference
±0.02°
±2°
Front set back
±0.02°
±2°
Rear set back
±0.02°
±2°
