FCI ST100 series Operation Manual

ST100 Series HART
18 Fluid Components International LLC
HART COMM NUMB. HART COMMAND DESCRIPTION HART DATA TYPE & SIZE
170
READ BANK #1 OF SENSOR VARIABLES
FLOW VALUE -SENSOR #1 FLOW1_VAL
FLOAT (4BYTES)
TEMPERATURE VAL SENSOR#1 TEMP1_VAL
FLOAT (4BYTES)
PRESSURE VALUE SENSOR#1 PRESS1_VAL
FLOAT (4BYTES)
FLOW VALUE -SENSOR #2 FLOW2_VAL
FLOAT (4BYTES)
TEMPERATURE VAL SENSOR#2 TEMP2_VAL
FLOAT (4BYTES)
PRESSURE VALUE SENSOR#2 PRESS2_VAL
FLOAT (4BYTES)
FLOW VALUE -SENSOR #3 FLOW3_VAL
FLOAT (4BYTES)
TEMPERATURE VAL SENSOR#3 TEMP3_VAL
FLOAT (4BYTES)
PRESSURE VALUE SENSOR#3 PRESS3_VAL
FLOAT (4BYTES)
FLOW VALUE -SENSOR #4 FLOW4_VAL
FLOAT (4BYTES)
TEMPERATURE VAL SENSOR#4 TEMP4_VAL
FLOAT (4BYTES)
PRESSURE VALUE SENSOR#4 PRESS4_VAL
FLOAT (4BYTES)
151
READ CAL FLOW LIMITS
FLOW LOWER LIMIT FLOW_LO_LIM
FLOAT (4BYTES)
FLOW UPPER LIMIT FLOW_UP_LIM
FLOAT (4BYTES)
154
READ CAL TEMP. LIMITS
TEMPERATURE LOWER LIMITS TEMP_LO_LIM
FLOAT (4BYTES)
TEMPERATURE UPPER LIMITS TEMP_UP_LIM
FLOAT (4BYTES)
157
READ CAL PRESS. LIMITS
PRESSURE LOWER LIMIT PRESS_LO_LIM
FLOAT (4BYTES)
PRESSURE UPPER LIMIT PRESS_UP_LIM
FLOAT (4BYTES)
