6
ST100 Series Probus PA
Service Transducer Block Parameters
The Service Transducer Block is a manufacturer specific block that contains ST100 configuration and setup parameters so that some configuration can
be done from the control room through PROFIBUS PA. It facilitates the changing of pipe size dimensions, restoring the current cal group to the original
factory values. It also allows the user to change flow type from Volumetric, Mass Flow, and Velocity. This block also allows activation and deactiva-
tion of the ST100 FCI TOTALIZER. And finally for the multi-point models of the ST100, this block allows viewing of each individual sensor variables for
the purpose of troubleshooting.
REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE SIZE READ/WRITE
8 FLOW_TYPE 10 24 UNSIGNED 8 D 1 RW
9 TOTALIZER_STATE 10 25 UNSIGNED 8 D 4 RW
10 PLENUM_SIZE_VALUE1 10 26 FLOAT D 4 RW
11 PLENUM_SIZE_VALUE2 10 27 FLOAT D 4 RW
12 WRITE_PROTECT_MODE 10 28 UNSIGNED 8 D 1 RW
13 FACTORY_RESTORE 10 29 UNSIGNED 8 D 1 RW
14 DEVICE_CO 10 30 OCTETSTRING D 10 R
15 DEVICE_SERIAL_NUM 10 31 OCTETSTRING D 10 R
16 DEVICE_SFTWR_VER 10 32 OCTETSTRING D 4 R
17 SENSORS_BANK_1 10 33 FLOAT D 48 R
Fluid Components International LLC
