ST100 Series Probus PA
System Blocks Description
Physical Block Parameters
This block contains general PROFIBUS PA instrument information. This information helps to identify the device in the network, it’s software version,
hardware version as well as control some of it instrument level functions.
REL. INDEX PARAMETER SLOT INDEX DATA TYPE (LENGTH) STORE SIZE READ/WRITE
8 SOFTWARE_REVISION 0 24 VISIBLESTRING C 16 R
9 HARDWARE_REVISION 0 25 VISIBLESTRING C 16 R
10 DEVICE_MAN_ID 0 26 UNSIGNED 16 C 2 R
11 DEVICE_ID 0 27 VISIBLESTRING C 16 R
12 DEVICE _SER_NUM 0 28 VISIBLESTRING C 16 R
13 DIAGNOSIS 0 29 OCTETSTRING D 4 R
14 DIAGNOSIS_EXTENSION 0 30 OCTETSTRING D 6 R
15 DIAGNOSIS_MASK 0 31 OCTETSTRING C 4 R
16 DIAGNOSIS_MASK_EXTENSION 0 32 OCTETSTRING C 6 R
17 DEVICE_CERTIFICATION 0 33 VISIBLESTRING C 32 R
18 WRITE_LOCKING 0 34 UNSIGNED 16 N 2 RW
19 FACTORY_RESET 0 35 UNSIGNED 16 S 2 RW
20 DESCRIPTOR 0 36 OCTETSTRING S 32 RW
21 DEVICE_MESSAGE 0 37 OCTETSTRING S 32 RW
22 DEVICE_INSTAL_DATE 0 38 OCTETSTRING S 16 RW
23 NOT USED 0 39
24
IDENT_NUMBER_SELECTOR 0 40 UNSIGNED8 S 1 RW
25 HW_WRITE_PROTECTION 0 41 UNSIGNED8 D 1 R
26 FEATURE 0 42 DS-68 N 8 R
27 COND_STATUS_DIAG 0 43 UNSIGNED8 S 1 RW
28 DIAG_EVENT_SWITCH 0 44 DIAG_EVENT_SWITCH S 50 RW
29-32 RESERVED BY PNO 0 45-48
