Order Information Sheet (OIS)
ST5
1
Biogas & Natural Gas Insertion Flow Meter
INSTRUCTIONS: To order an ST51, please fill in each numbered block above by selecting required codes from the corresponding categories below. Use of any “W” or “
*
” codes requires prior approval
from FCI. For special data, documentation, test reports or required quality reports, refer to FCI’s Engineering and Quality Assurance Order Information Sheets (OIS).
ST
51
-
0
Block No. 1 2 3 4 5 6 7 8
© Copyright 2010 Fluid Components International LLC. All rights reserved. Subject to change without notice. Order Information Sheet effective 08/2013 Doc. No. 01SA011465 B Page 1 of 2
Code
[BLOCK 5
]
Gas Medium and Calibration
2
For Biogas, Digester Gas, Natural Gas, Methane, Flue Gas and Other Hydrocarbon Mixed Gases
C
Customized air equivalency: 0.75 SFPS to 100 SFPS; 10 psia to 50 psia [0,2 NMPS to
30 NMPS; 0,7 to 3,5 bar (a)]
1
Natural gas (90% or greater methane content)
F
Customized actual gas
For Air, Nitrogen or Compressed Air Calibration
A
Standard; 1.25 SFPS to 125 SFPS;
10 psia to 50 psia [0,4 NMPS to 38 NMPS; 0,7 bar (a) to 3,5 bar (a)]
7
B
Customized; 0.75 SFPS to 150 SFPS;
10 psia to 50 psia [0,2 NMPS to 45,7 NMPS; 0,7 bar (a) to 3,5 bar (a)]
D
Standard; 4 SFPS to 400 SFPS;
50 psia to 165 psia [1,2 NMPS to 122 NMPS; 3,5 bar (a) to 11,4 bar (a)]
6, 7
E
Customized; 4 SFPS to 400 SFPS;
50 to 165 Psia [1,2 NMPS to 122 NMPS; 3,5 bar (a) to 11,4 bar (a)]
6
W
Factory approved, customer specified, special calibration
Code [ Block 6 ]
Calibration
4
and Calibration Conditi ons
Temperature, Vortab Flow Conditioner, Flat Flow Profile
0
Standard 2% accuracy calibration and conditions 40 °F to 100 °F [4 °C to 38 °C]
A
Standard 2% accuracy calibration and extended temperature compensation
0 °F to 250 °F [-18 °C to 121 °C]
M
High accuracy 1% calibration and standard conditions 40 °F to 100 °F [4 °C to 38 °C]
N
High accuracy 1% calibration and extended temperature compensation
0 °F to 250 °F [-18 °C to 121 °C]
Q
High accuracy 1% calibration with Vortab (VEL, VFK, VIS, VMR or VSR)
5
High accuracy 1% calibration with Vortab (VIP)
T
High accuracy 1% calibration and extended temperature compensation
0 °F to 250 °F [-18 °C to 121 °C] and Vortab (VEL, VFK, VIS, VMR or VSR)
6
High accuracy 1% calibration and extended temperature compensation
0 °F to 250 °F [-18 °C to 121 °C] and Vortab (VIP)
R
High accuracy 1% calibration, at flat flow profile
U
High accuracy 1% calibration and extended temperature compensation
0 °F to 250 °F [-18 °C to 121 °C] and flat flow profile
(continued next page)
Code
[
BLOCK 1
]
Base Unit, Enclosure Style, Power Supply
Enclosures: all aluminum, NEMA4X/IP67 rated, epoxy coated
1
Blind, integral transmitter with two 1/2 ″ FNPT cable entries
18 Vdc to 36 Vdc powered
2
Blind, integral transmitter with two 1/2 ″ FNPT cable entries
85 Vac to 265 Vac powered
3
Integral transmitter with local digital display, with two 1/2 ″ FNPT cable entries
18 Vdc to 36 Vdc powered
4
Integral transmitter with local digital display, with two 1/2 ″ FNPT cable entries
85 Vac to 265 Vac powered
7
Remote transmitter with two 1/2 ″ FNPT cable entries and with digital display
(specify cable length in Block 8)18 Vdc to 36 Vdc powered
8
Remote transmitter with two 1/2” FNPT cable entries and with digital display
(specify cable length in Block 8) 85 Vac to 265 Vac powered
A
Blind, integral transmitter with two M20x1.5 cable entries
18 Vdc to 36 Vdc powered
B
Blind, integral transmitter with two M20x1.5 cable entries
85 Vac to 265 Vac powered
C
Integral transmitter, with local digital display, with two M20x1.5 cable entries
18 Vdc to 36 Vdc powered
D
Integral transmitter, with local digital display, with two M20x1.5 cable entries
85 Vac to 265 Vac powered
E
Remote transmitter with two M20x1.5 cable entries and with digital display (specify
cable length in Block 8) 18 Vdc to 36 Vdc powered
F
Remote transmitter with two M20x1.5 cable entries and with digital display (specify
cable length in Block 8) 85 Vac to 265 Vac powered
Code
[
BLOCK 2
]
Pipe Installation, Display / Transmitter Mounting Orientation
and Flow Direction
Code Horizontal Pipe Code Vertical Pipe
F
Top mount, display facing forward,
flow left-to-right
M
Side mount left, display facing
forward, flow up
G
Top mount, display facing forward,
flow right-to-left
N
Side mount right, display facing
forward, flow up
H
Side mount, display facing up,
flow left-to-right
P
Side mount left, display facing
forward, flow down
J
Side mount, display facing up,
flow right-to-left
R
Side mount right, display facing
forward, flow down
K
Side mount, display facing down,
flow left-to-right
For visual representation, see FCI drawing
number 021263 on page 2
L
Side mount, display facing down,
flow right-to-left
Code
[BLOCK 3
]
Process Connection / Ferrule Material
1
1/2
″
male NPT / Teflon ferrule
2
1/2
″
male NPT / metal ferrule
3
3/4
″
male NPT / Teflon ferrule
4
3/4
″
male NPT / metal ferrule
Code
[BLOCK 4
]
Insertion Length
1
6
″
[152 mm] maximum “U” length
2
12
″
[305 mm] maximum “U” length
3
18
″
[457 mm] maximum “U” length
To Next Page
