89
Service Parts
PCAP Display Module
MO-PNC1
Gasket that comes with AUO P-CAP
Touch Screen 15" with EETI Touch
Controller
MO-BC23 Screw (2#)M3×5
MO-TPC3
Metal bracket for 15" Panel
MO-THC1
Plastic front frame (with power button)
MO-THC4
15"AUO P-CAP touch panel
MO-PNC2 Conductive EMI for Panel
MO-TPC4
Touch Cable Molex51021
30cm
MO-PNC4 Left & Right foam strip for 15" LCD
MO-PNC1 AUO P-CAP Touch Screen 15" with EETI Touch Controller
MO-PNC3
Top & Bottom foam strip for 15" LCD
