4.3 Factory settings
To restore the factory default parameters, proceed as follows:
1) Press button 6x briefly until
shows on the LEDs.
2) Hold button down Æ After one second all LEDs flash rapidly.
After two seconds the LEDs go out.
3) Release button. Æ The essential detector parameters are now set as follows :
Parameter Value Description Comments
Frequency 0 automatic frequency setting depending on device address
Hardware output
Output mode
Inversion
Error output
3
0
0
normal output
not inverting
no loop errors
Standard hardware output for loop
assignment
Loop parameters
Classification module 1
and 2
Head gap 250 cm TLS II loop
Length adjustment 0
Amplitude factor 100 TLS II loop
Loop length 100 cm TLS II loop
Output parameters
Classification module 1
Outputs 1 and 2
Loop assignment
1
2
Output 1: loop 1
Output 2: loop 2
Outputs 1 and 2
Output function
1 Presence
Output parameters
Classification module 2
Outputs 3 and 4
Loop assignment
1
2
Output 3: loop 4
Output 4: loop 4
Outputs 3 and 4 -
Output function
1 Presence
Address offset 48 Offset
version dependent if necessary !
RS485 port
Baud rate
Parity
Parity detection
4
0
1
9600 Baud
even
active
Refer to the RS485 protocol specification for the basic setting of other parameters !
