BOP 6 (A); BOP 10 (A); BOP 10-2 (A); BOP 13-2 (A)
6. Removal
C-SC_CSSM
Version 1.0
2017-10-12
All rights reserved by FEIN, especially in case of property rights applications.
FEIN retains all rights of disposal, such as copying and circulation.
Page 20 of 65
Removing the gearbox housing [applies to: BOP 13-2 (A)]
1. Remove the clutch ring (1) and the rollers (2).
2. Remove the grooved ball bearing (3).
1. Remove the circlip (4).
Tools:
- Inner puller
- Circlip pliers
1
3
4
2
